Machine Maintenance: 5-12
Extracting Seals
With manifold removed from crankcase:
1. Insert proper extractor collet through main seal retainer (see Figure 5-11).
2. Tighten collet and extract retainers and seals.
The Teon seals of the HT series will be damaged during disassembly so new
ones with have to be installed.
Figure 8-11. Extract Retainers and Seals
