Height ： The distance between the cutting head and the board surface is displayed
within the capacitance measurement range.
Capacity： The principle of system sampling is to obtain the distance by measuring the
capacitance between the cutting head and the plate. The closer the cutting head is to the
sheet, the larger the capacitance value(but the displayed capacitance value will become
smaller). When the floating head hits the plate, the capacitance will change to zero.
3.3 Menu structure
