Reference point 4
6.00mm
9.00mm
12.00mm
15.00mm
Reference point 5
5.00mm
7.50mm
10.00mm
12.50mm
Reference point 6
4.00mm
6.00mm
8.00mm
10.00mm
Reference point 7
3.00mm
4.50mm
6.00mm
7.50mm
Reference point 8
2.50mm
3.75mm
5.00mm
6.25mm
Reference point 9
2.00mm
3.00mm
4.00mm
5.00mm
Reference point 10
1.80mm
2.70mm
3.60mm
4.50mm
Reference point 11
1.50mm
2.25mm
3.00mm
3.75mm
Reference point 12
1.20mm
1.80mm
2.40mm
3.00mm
Reference point 13
1.00mm
1.50mm
2.00mm
2.50mm
Reference point 14
0.70mm
1.05mm
1.40mm
1.75mm
Reference point 15
0.50mm
0.75mm
1.00mm
1.25mm
Reference point 16
0.20mm
0.30mm
0.40mm
0.50mm
Nozzle Lost
>30.00mm
>30.00mm
>30.00mm
>30.00mm
[NOZZLE LOST] detection function
The following steps are mandatory steps, otherwise the entire calibration process is
invalid.
1. Set the CAL.REQUEST signal (PIN A3, High)
2. Move the sensor away from the workpiece, the distance should be greater than 30mm
3. Keep the entire position for at least 200ms to calibrate NOZZLE LOST
4. Reset the CAL.REQUEST signal (PIN A3, Low)
If an error occurs during the calibration of the reference point, the COLLISION (PIN A11,
High) signal will be set.
If the calibration fails, repeat the above steps.
