Powermax125 Operator Manual 808080 Revision 0 103
7 – Mechanized Cutting
Serial port cables
The following serial cables are available with the specified lengths and connectors:
223236 – RS-485 cable, unterminated, 7.6 m (25 feet)
223237 – RS-485 cable, unterminated, 15 m (50 feet)
223239 – RS-485 cable, 9-pin D-sub connector for Hypertherm controls, 7.6 m (25 feet)
223240 – RS-485 cable, 9-pin D-sub connector for Hypertherm controls, 15 m (50 feet)
Using the machine torch
Since the Powermax with a machine torch can be used with a wide variety of cutting tables, track burners, pipe bevelers,
and so on, you will need to refer to the manufacturer’s instructions for specifics on operating the machine torch in your
configuration. However, the following topics will help you optimize cut quality and maximize consumable life.
Setting up the torch and table
Use a square to align the torch at right angles to the workpiece in two dimensions.
The torch may travel more smoothly if you clean, check, and “tune” the cutting table’s rails and drive system. Unsteady
machine motion can cause a regular, wavy pattern on the cut surface.
Ensure that the torch does not touch the workpiece during cutting. Contact with the workpiece can damage the
shield and nozzle and affect the cut surface.
Understand and optimize cut quality
Several factors affect cut quality:
Cut angle – The degree of angularity of the cut edge.
Dross – The molten material that solidifies on the top or bottom of the workpiece.
Straightness of the cut surface – The cut surface can be concave or convex.
The following topics explain how these factors can affect cut quality.
