Powermax125 Operator Manual 808080 Revision 0 81
6 – Machine Torch Setup
125 A shielded cutting – aluminum
Air flow rate – slpm/scfh
Hot 260 / 550
Cold 345 / 730
Metric
Material
Thickness
Torch-to-Work
Distance
Initial Pierce Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
mm mm mm % seconds mm/min volts mm/min volts
6
4.6
9.2 200
0.2 7660 159 8560 156
8 0.3 5100 161 6100 157
10 0.4 2980 163 4020 159
12 0.5 2140 165 3070 162
16
11.5 250
0.6 1540 169 2090 163
20 2.0 1260 170 1500 167
25 3.5 850 174 1050 167
30
Edge Start
1.0 810 175 760 167
32 1.1 430 182 750 174
35
1.2
370 183 580 176
40 270 185 300 179
English
Material
Thickness
Torch-to-Work
Distance
Initial Pierce Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
inches inches inches % seconds ipm volts ipm volts
1/4
0.18
0.36 200
0.2 284 159 320 156
3/8 0.4 124 163 166 158
1/2 0.5 80 166 114 162
5/8
0.45 250
0.6 61 169 83 163
3/4 0.8 52 170 62 167
7/8 2.0 44 171 52 167
13.53217540167
1-1/4
Edge Start 1.0
17 182 30 174
1-1/2 12 184 16 178
