32 Powermax125 Operator Manual 808080 Revision 0
2 – Power Supply Setup
L1
L2
L3
L1
L2
L3
Ground
419 mm (16.5 inches)
203 mm
(8 inches)
6mm (0.25inch)
Route lead through strain relief
and tighten
CSA/CCC power cords
(no ferrite cores)
CE power cord
(ferrite cores on power
wires and ground wire)
