Hypertherm powermax45 Operator's Manual

POWER SUPPLY SETUP
2-6 powermax 45 Operator Manual
Input
voltage Phase < 10 ft 10–25 ft 25–50 ft 50–100 ft 100–150 ft
208 VAC 1 8 AWG 8 AWG 8 AWG 6 AWG 4 AWG
220 VAC 1 8 AWG 8 AWG 8 AWG 6 AWG 4 AWG
200–240 VAC 1 8 AWG 8 AWG 8 AWG 6 AWG 4 AWG
380 VAC 3 12 AWG 12 AWG 12 AWG 10 AWG 10 AWG
400 VAC
3
12 AWG 12 AWG 12 AWG 10 AWG 10 AWG
Extension cord recommendations
English
Metric
Input
voltage Phase < 3 m 3–7.5 m 7.5–15 m 15–30 m 30 –45 m
208 VAC 1 10 mm
2
10 mm
2
10 mm
2
16 mm
2
25 mm
2
220 VAC 1 10 mm
2
10 mm
2
10 mm
2
16 mm
2
25 mm
2
200–240 VAC 1 10 mm
2
10 mm
2
10 mm
2
16 mm
2
25 mm
2
380 VAC 3 4 mm
2
4 mm
2
4 mm
2
6 mm
2
6 mm
2
400 VAC
3
4 mm
2
4 mm
2
4 mm
2
6 mm
2
6 mm
2
