OPERATION
powermax
45
Operator Manual 4-15
How to use the machine torch
Since the Powermax45 and the T45m can be used with a wide variety of cutting tables, track
burners, pipe bevelers, and so on, you will need to refer to the manufacturer’s instructions for
specifics on operating the machine torch in your configuration. However, the information in the
following sections will help you optimize cut quality and maximize consumable life.
Ensure the torch and table are set up correctly
• Use a square to align the torch at right angles to the workpiece.
• The torch may travel more smoothly if you clean, check and “tune” the cutting table’s rails and
drive system. Unsteady machine motion can cause a regular, wavy pattern on the cut surface.
• Ensure that the torch does not touch the workpiece during cutting. Contact with the
workpiece can damage the shield and nozzle and affect the cut surface.
Understand and optimize cut quality
There are several factors to consider in cut quality:
• Cut angle — The degree of angularity of the cut edge.
• Dross — The molten material that solidifies on the top or bottom of the workpiece.
• Straightness of the cut surface — The cut surface can be concave or convex.
The following sections explain how these factors can affect cut quality.
Cut or bevel angle
• A positive cut angle, or bevel, results when more material is removed from the top of the cut
than from the bottom.
• A negative cut angle results when more material is removed from the bottom of the cut.
