Hypertherm powermax45

TORCH SETUP
powermax 45 Operator Manual 3-13
Recommended Maximum
Arc
current
(amps)
Material
thickness
(mm)
Torch-
to-work
distance
(mm)
Initial pierce
height
Pierce
time delay
(sec)
Cut
Speed
(mm/min)
Voltage
(V)
Cut
Speed
(mm/min)
Voltage
(V)
30
1.2
1.5 3.8 mm 250%
0.0 9150 117 10160* 120
1.5
0.2
8650 118 10160* 121
1.9 5450 118 6860 121
45
1.5
1.5
3.8 mm 250%
0.0
9150 116 10160* 114
1.9 8650 117 10160 116
2.7 7100 120 9144 119
3.4 0.1 5600 122 7112 120
4.8 0.2 2550 123 3302 120
6.4 0.3 2050 123 2540 120
9.5 0.5 840 130 1067 125
12.7
Edge start recommended
510 134 635 130
19.1 200 143 254 138
T45m shielded consumables
Aluminum
Metric
Air flowrate (lpm)
Hot 151
Cold 165.2
*Maximum cut speed is limited by the test table’s maximum speed (10160 mm/min).
