Hypertherm powermax45 Operator's Manual

TORCH SETUP
3-18 powermax 45 Operator Manual
Recommended Maximum
Arc
current
(amps)
Material
thickness
Torch-
to-work
distance
(in)
Initial pierce
height
Pierce
time delay
(sec)
Cut
Speed
(ipm)
Voltage
(V)
Cut
Speed
(ipm)
Voltage
(V)
30
0.018 in
(26 Ga)
0.08 0.2 in 250%
0.0
360 113 400* 125
0.030 in
(22 Ga)
320 115 400* 128
0.036 in
(20 Ga)
275 114 345 125
0.060 in
(16 Ga)
0.2 145 112 180 118
45
0.036 in
(20 Ga)
0.08
0.2 in 250%
0.0
350 112 400* 110
0.060 in
(16 Ga)
320 115 400* 113
0.075 in
(14 Ga)
0.1 280 116 360 114
0.105 in
(12 Ga)
0.3 160 118 200 116
0.135 in
(10 Ga)
0.4 110 120 140 118
0.188 in
(3/16 in)
0.5 64 120 80 118
0.250 in
(1/4 in)
0.6 40 121 50 118
0.375 in
(3/8 in)
0.8 24 125 30 120
0.500 in
(1/2 in)
Edge start recommended
14 130 18 126
0.750 in
(3/4 in)
7 133 9 138
T45m unshielded consumables
Stainless steel
English
Air flowrate (scfh)
Hot 320
Cold 350
*Maximum cut speed is limited by the test table’s maximum speed (400 ipm).
