Hypertherm powermax45 Operator's Manual

MAINTENANCE AND REPAIR
5-12 powermax 45 Operator Manual
9. Reattach the filter bowl.
10. Reposition the filter assembly in the bracket and replace its retainer nut.
11. Reconnect the gas supply hose and press the drain hose onto the drain in the bottom of the
power supply.
12. Reconnect the gas supply and check for leaks.
13. Slide the cover back onto the power supply. Position the handle over the holes in the top of
the cover, then use the 2 screws to secure the cover.
14. Reconnect the electrical power and the gas supply.
