Install and Set Up the Plasma Power Supply
42 810470 Operator Manual Powermax65/85/105 SYNC
The recommended fuse sizes let spikes in input current occur when you
stretch the plasma arc. Stretching the plasma arc is common in some
applications, such as gouging.
Powermax65 SYNC
CSA configurations (1-phase)
CSA configurations (3-phase)
CE/CCC configurations (3-phase)
Input voltage at 50 Hz/60 Hz* 200 V – 208 V 230 V – 240 V 480 V
Input current at rated output (65 A × 139 VDC = 9.0 kW) 52 A / 50 A 44 A 22 A
Input current during arc stretch 74 A 74 A 38 A
Fuse (time-delay) 80 A 80 A 40 A
* All models have a voltage tolerance of +10% / -15%.
Input voltage at 50Hz/60Hz* 200V– 208V 230V– 240V 400V 480V – 600V
Input current at rated output
(65 A × 139 VDC = 9.0 kW)
32 A / 31 A 27 A 15 A 13 A
Input current during arc stretch 45 A 45 A 27 A 23 A
Fuse (time-delay) 50 A 50 A 30 A 25 A
* All models have a voltage tolerance of +10% / -15%.
Input voltage at 50 Hz/60 Hz* 380 V 400 V
Input current at rated output (65 A × 139 VDC = 9.0 kW) 15.5 A 15 A
Input current during arc stretch 27 A 27 A
Fuse (time-delay) 30 A 30 A
* All models have a voltage tolerance of +10% / -15%.
