Hypertherm SYNC Powermax 65 - Plasma Power Supply Dimensions and Weights; Powermax65 SYNC and Powermax85 SYNC

Install and Set Up the Plasma Power Supply
2
38 810470 Operator Manual Powermax65/85/105 SYNC
Plasma power supply dimensions and weights
Powermax65 SYNC and Powermax85 SYNC
Figure 1 – Powermax65 SYNC and Powermax85 SYNC dimensions
Table 1 – Powermax65 SYNC and Powermax85 SYNC weights with power cords

For hand torch weights, refer to Weights on page 110. For machine torch
weights, refer to the Powermax65/85/105 SYNC Mechanized Cutting
Guide (810480).
Powermax65 SYNC Powermax85 SYNC
200 V – 600 V CSA 380 V CCC / 400 V CE 200 V – 600 V CSA 380 V CCC / 400 V CE
24.3 kg (54 lb) 20.6 kg (45 lb) 27.2 kg (60 lb) 23.5 kg (52 lb)
233 mm
(9.2 inches)
483 mm
(19 inches)
430 mm
(17 inches)
354 mm
(13.9 inches)
