16
1.3 Operation manuals related to this product, which are contained in
the operation manual (CD).
No. Name Manual No.
1 ASEP/PSEP Op
eration Manual (This Manual) ME0216
2 Touch pa
nel teaching tool specially for PSEP/ASEP SEP-PT ME0217
3 PC Software R
CM-101-MW/RCM-101-USB Operation Manual ME0155
1.4 How to read the model plate
Model
Serial number
1.5 How to read the model of the controller
A S E P - C - 2 0 I - N P - 0 - 0 - A B U
[ASEP]
P S E P - C - 2 0 P I - N P - 0 - 0 - A B U
[PSEP]
<Series>
<Type Name>
C : Standard type
CW : Dust-proof type (Equivalent to IP53)
<Actuator Characteristics>
[Motor Type]
2 :2W 20S :20W(For RCA-R□3, RCA2-SA4/TA5)
5 :5W 30 :30W
10 :10W
20 :20W
[Encoder type]
I : Incremental
[Option]
LA : Power Consumption Type
<Series>
<Type Name>
C : Standard type
CW : Dust-proof type (Equivalent to IP53)
<Actuator Characteristics>
[Motor Type]
20P :20 angles 35P :35 angles
28P :28 angles 42P :42 angles
28SP :28 angles 56P :56 angles
(For RA3C)
[Encoder type]
I : Incremental
<I/O signal pattern>
NP :NPN Specification (Sync. Type) (Standard)
PN :PNP Specification (Source Type)
<Applicable to Simplified Absolute Unit>
ABU : Simplified Absolute Type
(With the Absolute Battery Unit)
No description : Incremental Type
<Power-supply voltage>
0 :DC24V
<I/O cable length>
0 :No Cable 3 :3m
2 :2m 5 :5m
<I/O signal pattern>
NP :NPN Specification(Sync. Type)(Standard)
PN :PNP Specification(Source Type)
<Applicable to Simplified Absolute Unit>
ABU : Simplified Absolute Type
(With the Absolute Battery Unit)
No description : Incremental Type
<Power-supply voltage>
0 :DC24V
<I/O cable length>
0 :No Cable 3 :3m
2 :2m 5 :5m
L
A
