IAI ASEP Operation Manual

33
10. Setting
[1] Initial Setting
Perform the following settings using the PC Software unit (RCM-101-***) or touch panel teaching unit
(SEP-PT).
After the purchase of the unit, when the power to the unit is turned ON for the rst time, a window for
sel
ecting whether or not the initial setting is performed, is displayed.
[Refer to the PC Software or SEP-PT Operation Manual for the details of setting procedure]
• Initial Setting Items
*There may be some items that are not displayed depending on the selected
operation patterns.
No. Setting Items
Setting Range
(Set in delivery)
Contents
PIO Pattern
0 1 2 3 4 5
1 PIO Pattern
(
Operation
Pattern)
0 to 5 (0) Set it to the pattern to be used.
○ ○ ○ ○ ○ ○
2 O
peration
Mo
de
(Solenoid
System)
Single/Double
(Double)
It is selectable only when the PIO pattern is set to “0”,
“1” or “2”. Select “Single” (single solenoid system) or
“Double” (double solenoid system).
○ ○ ○
3 Stop Si
gnal Enable/Disable
(Disable)
It is selectable only when “Single” is selected in “2.
Operation Mode (Solenoid System)”.
When the PAUSE signal (*STP) is used, select “Enable”.
○ ○ ○ ○
4 I
nput Si
gnal
System
(Solenoid
Type)
Continuous
Operation Type
/Momentary
Operation Type
(Continuous
Operation Type)
It is selectable only when “Double” is selected in “2.
Operation Mode (Solenoid System)”.
For the signal sent from PLC to ASEP or PSEP, select
“Continuous Operation” (level signal) or “Momentary
Operation” (edge signal).
○ ○ ○ ○
5 Intermediate
St
op System
Both Solenoids ON
/Both Solenoids
OFF
(Both Solenoids
OFF)
It is selectable only when the PIO pattern is set to “3”.
In the case the same use procedure as for 5-port
3-position electromagnetic valve is applied, select “Both
Solenoid OFF”.
In the case that the same use procedure as the
time when two units of the 3-port single solenoid
electromagnetic valve, are used, select “Both Solenoid
ON”.
○
6 Servo-motor
Co
ntrol
Enable/Disable
(Disable)
When “Disable” is selected, the servo-motor is
automatically turned ON after the power input.
When “Enable” is selected, the servo-motor is turned ON
by means of turning ON the SON signal on INPUT IN3.
○ ○ ○ ○ ○ ○
7 Home
Po
sition
Operation
(Home Return
Operation
Procedure)
AUTO/MANU
(MANU)
When “AUTO” is selected, the home return operation
is started automatically after the power input. When
“MANU” is selected, the home return operation is
performed with the rst STO input.
○ ○ ○ ○ ○ ○
