6. Wiring
• Connection Example
LED for Absolute Battery STATUS monitoring
(For the absolute type)
LED for STATUS
SIO Connector
Touch panel teaching tool
specially for PSEP/ASEP
*It can not be connected to
SIO converter.
Host System(PLC)
Flat Cable
Accessories
PIO Connector
MPG Connector
Power Connector
FG Terminal Block
Actuator
Class D grounding
(Formerly Class-III grounding: Grounding resistance at 100Ω or less)
FG Cable:AWG16(1.25mm
2
)
Absolute Battery Unit
SEP-ABU
CB-APSEP-AB***
