IAI RCON-LC User Manual

Chapter 4 PLC Features
4.2 Commands
ME0416-1A 4-21
Assignment for other fieldbus types is as shown below:
Input and Output Domain Assignment for Fieldbus Communication: Other Networks
FB→LC
Output 0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
～
Output N
16N+15 16N
LC→FB
Input 0
16 (N+1) +15 16 (N+1)
～
Input N
16 (2N+19) +15 16 (2N+1)
N = S2 Setting -1
The range available for setting in S2 is as shown below.
S2 Settable Range in each Field Network
Network Type
S2 Setting
Min. Value
Max. Value
CC-Link
1
4
CC-Link IE
DeviceNet
16
PROFIBUS-DP
EtherNet/IP
EtherCAT
PROFINET-IO
As shown above, the settable range of S2 should differ in each field network type. The input and
output domains available for setting in each field network is as shown below.
Number of Max. Occupation in Input and Output Domains
Network Type
Output Domains
Output Domains
Bit Memories
Max. Occupied
Points
Min. Value Max. Value Min. Value Max. Value
CC-Link
3 words 24 words 3 words 24 words 768 points
CC-Link IE
DeviceNet
1 words 16 words 1 words 16 words 512 points
PROFIBUS-DP
EtherNet/IP
EtherCAT
PROFINET-IO
An error should be generated even when the setting in S2 is in the settable range if the value is
out of the available range of the indicated OM.
