Chapter pecications for unit
2.2
Extensi
on unit (PIO/SIO/SCON ex
tension unit, PI
O unit)
ME0416-1A
2-14
(2)
PIO cable c
onnector
Model
HIF6
-
40PA
-
1.27DS (71)
Manufacturer
Hirose E
lectri
c
Connector
General
Specifications
Rated current
0.5A
Rated voltage
125V AC
Repeated Inserti
on Life
500 times
* Refer to 2.2.5 PI
O Specifications f
or the assignment when usi
ng multiple PIO
c
onnectors.
PIO
cable connector
Output Side
Input Side
48
50
