Chapter pecications for unit
2.2
Extensi
on unit (PIO/SIO/SCON ex
tension unit, PI
O unit)
2-15
ME0416-1A
(3)
SIO cable c
onnector
Item
Model
Manufacturer
PCB side connector
MC1.5/3
-
GF
-
3.5P26THR
PHOENIX CONTACT
Mating Connector
FMC1.5/3
-
STF
-
3.5
PHOENIX CONTACT
Pin No.
Signal name
Description
1
ISO_GN
D
Grounding for extension communic
ation
2
ISO_SD
-
Extended communication line
-
3
ISO_SD+
Extended communication
line +
3
2
1
49
