Chapter  pecications for unit

2.2 Extension unit (PIO/SIO/SCON extension unit, PIO unit)

2-17 ME0416-1A

Shown below is the input assignments and output assignments when eight units in link.

Unit No.

Pin No. Category

Signal

name

Assignment Pin No. Category

Signal

name

Assignment

1A 24 P24 - 1B

Output

OUT0 Y000

2A 24 P24 - 2B OUT1 Y001

3A - - - 3B OUT2 Y002

4A - - - 4B OUT3 Y003

Input

IN0 X000 5B OUT4 Y004

6A IN1 X001 6B OUT5 Y005

7A IN2 X002 7B OUT6 Y006

8A IN3 X003 8B OUT7 Y007

9A IN4 X004 9B OUT8 Y008

10A IN5 X005 10B OUT9 Y009

11A IN6 X006 11B OUT10 Y00A

12A IN7 X007 12B OUT11 Y00B

13A IN8 X008 13B OUT12 Y00C

14A IN9 X009 14B OUT13 Y00D

15A IN10 X00A 15B OUT14 Y00E

16A IN11 X00B 16B OUT15 Y00F

17A IN12 X00C 17B - - -

18A IN13 X00D 18B - - -

19A IN14 X00E 19B 0 N -

20A IN15 X00F 20B 0 N -

1A 24 P24 - 1B

Output

OUT0 Y010

2A 24 P24 - 2B OUT1 Y011

3A - - - 3B OUT2 Y012

4A - - - 4B OUT3 Y013

Input

IN0 X010 5B OUT4 Y014

6A IN1 X011 6B OUT5 Y015

7A IN2 X012 7B OUT6 Y016

8A IN3 X013 8B OUT7 Y017

9A IN4 X014 9B OUT8 Y018

10A IN5 X015 10B OUT9 Y019

11A IN6 X016 11B OUT10 Y01A

12A IN7 X017 12B OUT11 Y01B

13A IN8 X018 13B OUT12 Y01C

14A IN9 X019 14B OUT13 Y01D

15A IN10 X01A 15B OUT14 Y01E

16A IN11 X01B 16B OUT15 Y01F

17A IN12 X01C 17B - - -

18A IN13 X01D 18B - - -

19A IN14 X01E 19B 0 N -

20A IN15 X01F 20B 0 N -

* The unit numbers are those numbered in order of 1, 2, …, 8 next to the LC unit.
