Chapter  pecications for unit

2.2 Extension unit (PIO/SIO/SCON extension unit, PIO unit)

ME0416-1A 2-18

Unit No.

Pin No. Category

Signal

name

Assignment Pin No. Category

Signal

name

Assignment

1A 24 P24 - 1B

Output

OUT0 Y020

2A 24 P24 - 2B OUT1 Y021

3A - - - 3B OUT2 Y022

4A - - - 4B OUT3 Y023

Input

IN0 X020 5B OUT4 Y024

6A IN1 X021 6B OUT5 Y025

7A IN2 X022 7B OUT6 Y026

8A IN3 X023 8B OUT7 Y027

9A IN4 X024 9B OUT8 Y028

10A IN5 X025 10B OUT9 Y029

11A IN6 X026 11B OUT10 Y02A

12A IN7 X027 12B OUT11 Y02B

13A IN8 X028 13B OUT12 Y02C

14A IN9 X029 14B OUT13 Y02D

15A IN10 X02A 15B OUT14 Y02E

16A IN11 X02B 16B OUT15 Y02F

17A IN12 X02C 17B - - -

18A IN13 X02D 18B - - -

19A IN14 X02E 19B 0 N -

20A IN15 X02F 20B 0 N -

1A 24 P24 - 1B

Output

OUT0 Y030

2A 24 P24 - 2B OUT1 Y031

3A - - - 3B OUT2 Y032

4A - - - 4B OUT3 Y033

Input

IN0 X030 5B OUT4 Y034

6A IN1 X031 6B OUT5 Y035

7A IN2 X032 7B OUT6 Y036

8A IN3 X033 8B OUT7 Y037

9A IN4 X034 9B OUT8 Y038

10A IN5 X035 10B OUT9 Y039

11A IN6 X036 11B OUT10 Y03A

12A IN7 X037 12B OUT11 Y03B

13A IN8 X038 13B OUT12 Y03C

14A IN9 X039 14B OUT13 Y03D

15A IN10 X03A 15B OUT14 Y03E

16A IN11 X03B 16B OUT15 Y03F

17A IN12 X03C 17B - - -

18A IN13 X03D 18B - - -

19A IN14 X03E 19B 0 N -

20A IN15 X03F 20B 0 N -

* The unit numbers are those numbered in order of 1, 2, …, 8 next to the LC unit.
