Chapter  pecications for unit

2.2 Extension unit (PIO/SIO/SCON extension unit, PIO unit)

2-19 ME0416-1A

Unit No.

Pin No. Category

Signal

name

Assignment Pin No. Category

Signal

name

Assignment

1A 24 P24 - 1B

Output

OUT0 Y040

2A 24 P24 - 2B OUT1 Y041

3A - - - 3B OUT2 Y042

4A - - - 4B OUT3 Y043

Input

IN0 X040 5B OUT4 Y044

6A IN1 X041 6B OUT5 Y045

7A IN2 X042 7B OUT6 Y046

8A IN3 X043 8B OUT7 Y047

9A IN4 X044 9B OUT8 Y048

10A IN5 X045 10B OUT9 Y049

11A IN6 X046 11B OUT10 Y04A

12A IN7 X047 12B OUT11 Y04B

13A IN8 X048 13B OUT12 Y04C

14A IN9 X049 14B OUT13 Y04D

15A IN10 X04A 15B OUT14 Y04E

16A IN11 X04B 16B OUT15 Y04F

17A IN12 X04C 17B - - -

18A IN13 X04D 18B - - -

19A IN14 X04E 19B 0 N -

20A IN15 X04F 20B 0 N -

1A 24 P24 - 1B

Output

OUT0 Y050

2A 24 P24 - 2B OUT1 Y051

3A - - - 3B OUT2 Y052

4A - - - 4B OUT3 Y053

Input

IN0 X050 5B OUT4 Y054

6A IN1 X051 6B OUT5 Y055

7A IN2 X052 7B OUT6 Y056

8A IN3 X053 8B OUT7 Y057

9A IN4 X054 9B OUT8 Y058

10A IN5 X055 10B OUT9 Y059

11A IN6 X056 11B OUT10 Y05A

12A IN7 X057 12B OUT11 Y05B

13A IN8 X058 13B OUT12 Y05C

14A IN9 X059 14B OUT13 Y05D

15A IN10 X05A 15B OUT14 Y05E

16A IN11 X05B 16B OUT15 Y05F

17A IN12 X05C 17B - - -

18A IN13 X05D 18B - - -

19A IN14 X05E 19B 0 N -

20A IN15 X05F 20B 0 N -

* The unit numbers are those numbered in order of 1, 2, …, 8 next to the LC unit.
