2.2 Extension unit (PIO/SIO/SCON extension unit, PIO unit)

ME0416-1A 2-20

Unit No.

Pin No. Category

Signal

name

Assignment Pin No. Category

Signal

name

Assignment

1A 24 P24 - 1B

Output

OUT0 Y060

2A 24 P24 - 2B OUT1 Y061

3A - - - 3B OUT2 Y062

4A - - - 4B OUT3 Y063

Input

IN0 X060 5B OUT4 Y064

6A IN1 X061 6B OUT5 Y065

7A IN2 X062 7B OUT6 Y066

8A IN3 X063 8B OUT7 Y067

9A IN4 X064 9B OUT8 Y068

10A IN5 X065 10B OUT9 Y069

11A IN6 X066 11B OUT10 Y06A

12A IN7 X067 12B OUT11 Y06B

13A IN8 X068 13B OUT12 Y06C

14A IN9 X069 14B OUT13 Y06D

15A IN10 X06A 15B OUT14 Y06E

16A IN11 X06B 16B OUT15 Y06F

17A IN12 X06C 17B - - -

18A IN13 X06D 18B - - -

19A IN14 X06E 19B 0 N -

20A IN15 X06F 20B 0 N -

1A 24 P24 - 1B

Output

OUT0 Y070

2A 24 P24 - 2B OUT1 Y071

3A - - - 3B OUT2 Y072

4A - - - 4B OUT3 Y073

Input

IN0 X070 5B OUT4 Y074

6A IN1 X071 6B OUT5 Y075

7A IN2 X072 7B OUT6 Y076

8A IN3 X073 8B OUT7 Y077

9A IN4 X074 9B OUT8 Y078

10A IN5 X075 10B OUT9 Y079

11A IN6 X076 11B OUT10 Y07A

12A IN7 X077 12B OUT11 Y07B

13A IN8 X078 13B OUT12 Y07C

14A IN9 X079 14B OUT13 Y07D

15A IN10 X07A 15B OUT14 Y07E

16A IN11 X07B 16B OUT15 Y07F

17A IN12 X07C 17B - - -

18A IN13 X07D 18B - - -

19A IN14 X07E 19B 0 N -

20A IN15 X07F 20B 0 N -

* The unit numbers are those numbered in order of 1, 2, …, 8 next to the LC unit.
