9. Installing the External Brake Connection Box for the Brake
Specification
If the actuator is equipped with a brake, an external brake connection box must be installed.
z External brake connection box Model: RCB-110-RA13-0
[Front view]
[Rear view]
External switch connector
24-V power-supply connector
Power ON switch
Connector for
actuator 1
Connector for
controller 1
Connector for
actuator 2
Connector for
controller 2
