3
4. Names of the Parts
The name of the actuator parts are indicated below.
In this manual, the left and right sides are indicated by looking at the actuator from the motor side in top
view.
4.1 Standard Specification
* The motor-reversing direction varies depending on the specification of the delivered product.
Caution: Even if you specified a robot cable, the cable extending from the actuator is not a robot
cable. Design an appropriate wiring layout so that this cable will not receive a flexing force.
The robot cable specification applies to the relay cable.
Rod Side
Right
Left
Connector box Pulley cover
Motor Side
Rod-tip adapter
luminum frame
Base Motor bracket
Rod
To Next Page
