IAI ROBO Cylinder RCS2 User Manual

4
4.2 Brake Specification
* The motor-reversing direction varies depending on the specification of the delivered product.
Caution: Even if you specified a robot cable, the cable extending from the actuator is not a robot
cable. Design an appropriate wiring layout so that this cable will not receive a flexing force.
The robot cable specification applies to the relay cable.
Rod Side
Right
Left
Connector box Pulley cover
Motor Side
Rod-tip adapter
A
luminum frame
Base
Motor bracket
Brake housing
Rod
