If the message indicates that the adapter is DEFINED instead of AVAILABLE, shut down the system unit
and check the PCIe2 3D Graphics Adapter to ensure that it is installed correctly. If you continue to
experience problems after following the steps in this section, contact service and support for assistance.
IBM Installation Toolkit for PowerLinux
To troubleshoot problems for the 3D Graphics adapter, you can use the IBM Installation Toolkit for
PowerLinux, a stand-alone diagnostic toolkit for systems that have the 3D Graphics adapter installed.
To diagnose problems with the 3D graphics adapter installed in a system, and work with the IBM
Installation Toolkit, complete the following steps:
1. Download the DVD ISO image from IBM Installation Toolkit website (http://www-304.ibm.com/
webapp/set2/sas/f/lopdiags/installtools/home.html).
2. Create a DVD for the downloaded ISO image.
3. Insert the DVD in the system DVD drive and boot the system.
Note: You can also use the NIM to boot the system.
4. Once the DVD has booted, select the 3D graphics diagnostics application.
5. Choose the option 2 - Wizard mode graphical (using X). The Graphical desktop is displayed.
6. Right-click on the desktop area, and click IBM > PCIe2 3D Graphics Adapter.
7. Follow the on-screen instructions to diagnose the problem with the 3D Graphics adapter and resolve
the problem.
Operating system or partition requirements
If you are installing a new feature, ensure that you have the software that is required to support the new
feature and that you determine whether any prerequisites must be met for this feature and attaching
devices. For information about operating system and partition requirements, see one of the following
topics:
• The latest version of enabling libraries and utilities can be downloaded from Fix Central
(http://
www.ibm.com/support/xcentral/).
• Power Systems Prerequisites (http://www14.software.ibm.com/support/customercare/iprt/home).
• IBM SSIC (System Storage Interoperation Center) (http://www-03.ibm.com/systems/support/storage/
ssic/interoperability.wss).
• The latest version of the device driver or IBM Power RAID adapter utilities (iprutils) can be downloaded
from the IBM Service and Productivity Tools website (http://www14.software.ibm.com/webapp/
set2/sas/f/lopdiags/home.html).
• For support details, see the Linux Alert website (http://www14.software.ibm.com/webapp/set2/sas/f/
lopdiags/info/LinuxAlerts.html).
PCIe2 LP 4-Port USB 3.0 Adapter (FC EC45 and FC EC46; CCIN 58F9)
Learn about the specications for the feature code (FC) EC45 and FC EC46 adapter.
The PCIe2 LP 4-Port USB 3.0 Adapter (FC EC45) is a PCI Express (PCIe) generation 2, low-prole, high-
performance expansion adapter. The FC EC45 is a low-prole adapter and the FC EC46 is regular-height
adapter. The adapters provide the following features and support:
• The adapter is compliant with PCIe base specication revision 2.
• The adapter is a single-lane (1x) PCI Express with a throughput of 5 Gbps.
• The adapter is a single-slot, half-length short form factor, PCIe2 card.
• The adapter is FCC Class A compliant.
• The adapter provides four downstream, external, high-speed Universal Serial Bus (USB) 3.0 ports with
Type A connectors.
• The USB ports are also compatible with USB specications, revision 1.1 and 2.0 devices.
104
Power Systems: Managing PCIe adapters
