Table 30. Cable matrix (continued)
Feature Description
EBBS QFSP56 Active Optical splitter cable, InniBand
HDR 200 Gb/S to 2X100GB/S - 10 M
EBBU QFSP56 Active Optical splitter cable, InniBand
HDR 200 Gb/S to 2X100GB/S - 20 M
EBBV QFSP56 Active Optical splitter cable, InniBand
HDR 200 Gb/S to 2X100GB/S - 30 M
Voltage
3.3 V, 12 V
Form factor
Short, low-prole (FC EC6G)
Attributes provided
PCI Express
®
4.0 (up to 16GT/s) x16
PCIe Gen 4.0 compliant (1.1, 2.0, and 3.0 compatible)
The adapter is based on the Mellanox ConnectX-6 adapter
Improves performance and scalability by offloading the CPU from I/O networking tasks
Minimizes CPU overhead by more efciently using memory access
Operating system or partition requirements
If you are installing a new feature, ensure that you have the software that is required to support the new
feature and that you determine whether any prerequisites must be met for this feature and attaching
devices. For information about operating system and partition requirements, see one of the following
topics:
• The latest version of enabling libraries and utilities can be downloaded from Fix Central
(http://
www.ibm.com/support/xcentral/).
• Power Systems Prerequisites (http://www14.software.ibm.com/support/customercare/iprt/home).
• IBM SSIC (System Storage Interoperation Center) (http://www-03.ibm.com/systems/support/storage/
ssic/interoperability.wss).
• The latest version of the device driver or IBM Power RAID adapter utilities (iprutils) can be downloaded
from the IBM Service and Productivity Tools website (http://www14.software.ibm.com/webapp/
set2/sas/f/lopdiags/home.html).
• For support details, see the Linux Alert website (http://www14.software.ibm.com/webapp/set2/sas/f/
lopdiags/info/LinuxAlerts.html).
PCIe3 cable adapter (FC EJ05; CCIN 2B1C)
Learn about the specications and operating system requirements for the feature code (FC) EJ05 adapter.
Overview
FC EJ05 is a double-wide, low-prole PCIe3 cable adapter. The adapter provides two optical ports for the
attachment of two expansion drawer cables. One adapter supports the attachment of one PCIe3 6-slot
fanout module in a EMX0 PCIe Gen3 I/O expansion drawer.
Note: The FC EJ05 (CCIN 2B1C) adapter only works with the CCIN 50CB PCIe3 6-slot fanout module.
Figure 41 on page 132 shows the adapter.
Managing PCIe adapters
131
