Slot requirement
For details about slot priorities, maximums, and placement rules, see PCIe adapter placement rules
and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER9/p9eab/
p9eab_mtm_pciplacement.htm) and select the system you are working on.
Thermal requirement
If you have an 8335-GTG, 8335-GTH, or 8335-GTX system, you might be required to set the thermal
mode of the system to a setting other than the default setting, depending on your system, adapter,
and cable type. For details, see Determining and setting the thermal mode for an 8335-GTG, 8335-
GTH, or 8335-GTX system.
Cables
For HDR 100 Gb, IBM offers either Direct Attach Copper (DAC) cables up to 2 M or Active Optical
Cables (AOC) up to 100 M. QSFP56 based transceivers are included on each end of these cables.
Cable matrix
The EDR cables that are listed in the table support connecting an HDR 100 Gb adapter to EDR 100 Gb
or HDR 200 Gb InniBand switches. The HDR 100 Gb splitter cables that are listed in the table
support connecting to an HDR 100 Gb adapter to an HDR 200 Gb switch.
Note: An HDR 200 Gb switch port must be in split-mode conguration when using the HDR 100 Gb
splitter cables.
Table 30. Cable matrix
Feature Description
EB50 Copper EDR 100 GbE cable - 0.5 M
EB51 Copper EDR 100 GbE cable - 1 M
EB54 Copper EDR 100 GbE cable - 1.5 M
EB52 Copper EDR 100 GbE cable - 2 M
EB5A Optical EDR 100 GbE cable - 3 M
EB5B Optical EDR 100 GbE cable - 5 M
EB5C Optical EDR 100 GbE cable - 10 M
EB5D Optical EDR 100 GbE cable - 15 M
EB5E Optical EDR 100 GbE cable - 20 M
EB5F Optical EDR 100 GbE cable - 30 M
EB5G Optical EDR 100 GbE cable - 50 M
EB5H Optical EDR 100 GbE cable - 100 M
EBBL QFSP56 Passive Copper splitter cable, InniBand
HDR 200 Gb/S to 2X100GB/S - 1.5 M
EBBK QFSP56 Passive Copper splitter cable, InniBand
HDR 200 Gb/S to 2X100GB/S - 1 M
EBBM QFSP56 Passive Copper splitter cable, InniBand
HDR 200 Gb/S to 2X100GB/S - 2 M
EBBQ QFSP56 Active Optical splitter cable, InniBand
HDR 200 Gb/S to 2X100GB/S - 3 M
EBBR QFSP56 Active Optical splitter cable, InniBand
HDR 200 Gb/S to 2X100GB/S - 5 M
130 Power Systems: Managing PCIe adapters
