• SAS RAID controllers for IBM i

• SAS RAID controllers for Linux

• SAS subsystem for the 9040-MR9

Managing PCIe adapters for the 9080-M9S system

Find information about using and managing the Peripheral Component Interconnect Express (PCIe)

adapters that are supported for the 9080-M9S system. Also, nd information about specications and

installation notes for specic adapters.

Overview of managing PCIe adapters for the 9080-M9S system

Find information about using and managing Peripheral Component Interconnect Express (PCIe) adapters.

The following features are electromagnetic compatibility (EMC) Class B features. See the Class B Notices

in the Hardware Notices section.

Table 8. Electromagnetic compatibility (EMC) Class B features

Feature Description

5748 POWER GXT145 PCI Express Graphics Accelerator

5785 4 Port Async EIA-232 PCIe Adapter

EN0W PCIe2 2-port 10 GbE BaseT RJ45 Adapter

The adapter information that is shown here is used during non-directed service activities. The information

can be used to:

• Identify an adapter

• Find specic technical information about an adapter

• Where applicable, show special installation or cabling instructions

• Show signal names for the output-pins of the adapter connectors

• Where applicable, show the settings for switches or jumpers

Adapters can be identied by their feature code (FC) or their custom-card identication number (CCIN).

Normally, the CCIN number is labeled on the adapter. The eld replaceable unit (FRU) part number (P/N)

of your adapter might not match the FRU P/N listed in this information. If the part numbers do not match,

verify that the CCIN is the same. If the CCIN is same, the adapter has the same function and can be used

in the same way.

Adapters must be placed in specic PCI Express (PCIe) slots to function correctly or optimally.

SAS RAID internal adapters and controllers for the 9080-M9S system

Find information about the PCIe3 SAS RAID internal adapters and controllers that are installed and

supported in the system.

Table 9 on page 10 provides information about the SAS RAID cards that are supported for the 9080-M9S

system.

Managing PCIe adapters
