Cables
Use multimode ber optic cables with shortwave lasers that adhere to the following specications:
• OM3: Multimode 50/125 micron ber, 2000 MHz x km bandwidth
• OM2: Multimode 50/125 micron ber, 500 MHz x km bandwidth
• OM1: Multimode 62.5/125 micron ber, 200 MHz x km bandwidth
Because core sizes are different, OM1 cables can only be connected to other OM1 cables. For best
results, OM2 cables should not be connected to OM3 cables. However, if an OM2 cable is connected to an
OM3 cable, the characteristics of the OM2 cable apply to the entire length of the cables. The following
table shows the supported distances for the different ber optic cable types at different link speeds.
Table 42. Supported distances for multimode ber optic cables
Header Cable Type and Distance
Rate OM1 OM2 OM3
2.125 Gbps 0.5 meters to 150
meters (1.64 feet to
492.12 feet)
0.5 meters to 300
meters (1.64 feet to
984.25 feet)
0.5 meters to 500
meters (1.64 feet to
1640.41 feet)
4.25 Gbps 0.5 meters to 70 meters
(1.64 feet to 229.65
feet)
0.5 meters to 150
meters (1.64 feet to
492.12 feet)
0.5 meters to 380
meters (1.64 feet to
1246.71 feet)
8.5 Gbps 0.5 meters to 21 meters
(1.64 feet to 68.89 feet)
0.5 meters to 50 meters
(1.64 feet to 164.04
feet)
0.5 meters to 150
meters (1.64 feet to
492.12 feet)
Operating system or partition requirements
If you are installing a new feature, ensure that you have the software that is required to support the new
feature and that you determine whether any prerequisites must be met for this feature and attaching
devices. For information about operating system and partition requirements, see one of the following
topics:
• The latest version of enabling libraries and utilities can be downloaded from Fix Central (http://
www.ibm.com/support/xcentral/).
• Power Systems Prerequisites (http://www14.software.ibm.com/support/customercare/iprt/home).
• IBM SSIC (System Storage Interoperation Center) (http://www-03.ibm.com/systems/support/storage/
ssic/interoperability.wss).
• The latest version of the device driver or IBM Power RAID adapter utilities (iprutils) can be downloaded
from the IBM Service and Productivity Tools website (http://www14.software.ibm.com/webapp/
set2/sas/f/lopdiags/home.html).
• For support details, see the Linux Alert website (http://www14.software.ibm.com/webapp/set2/sas/f/
lopdiags/info/LinuxAlerts.html).
PCIe2 FH 4-port 8 Gb Fibre Channel Adapter (FC EN12, CCIN EN0Y)
Learn about the specications and operating system requirements for the feature code (FC) EN12
adapter.
Overview
The PCIe2 FH 4-port 8 Gb Fibre Channel Adapter is a PCI Express (PCIe) generation-2, full-height, high-
performance, x8 short form factor plus (SFF+) Host Bus Adapter (HBA). This adapter enables multiple
logical (virtual) connections to share the same physical port. Each logical connection has its own
resources and the ability to be managed independently. Each port provides single initiator capability over
a ber link or provides multiple initiator capability with N_Port ID Virtualization (NPIV). The ports are
204
Power Systems: Managing PCIe adapters
