• For support details, see the Linux Alert website (http://www14.software.ibm.com/webapp/set2/sas/f/
lopdiags/info/LinuxAlerts.html).
Linux driver and rmware information
The 4767-002 Cryptographic Coprocessor's Linux drivers and rmware are not provided by the Linux
distribution. To install and or update the Linux drivers and rmware, the user must download the Power
Systems Linux drivers and rmware package. Refer to the IBM Power Systems information on the
4767-002 Cryptographic Coprocessor and follow the Linux drivers and rmware instructions at: Power
Systems Information for the 4767-002 Cryptographic Coprocessor (https://www-03.ibm.com/security/
cryptocards/pciecc2/overview.shtml).
PCIe3 16 Gb 2-port Fibre Channel adapter (FC EL43, FC EL5B, FC EN0A, and FC EN0B; CCIN 577F)
Learn about the specications and operating system requirements for the feature code (FC) EL43, EL5B,
FC EN0A, and FC EN0B adapter.
Overview
The PCIe3 16 Gb 2-port Fibre Channel adapter is an x8, generation 3 (gen3), PCIe adapter. This adapter
is a high-performance x8 short form adapter also referred to as a PCIe Host Bus Adapter (HBA). The
adapter provides two ports of 16 Gb Fibre Channel capability using SR optics. Each port can provide up to
16 Gb Fibre Channel functions simultaneously.
The FC EL43 and FC EN0B adapters are short, low-prole adapters and the FC EL5B and FC EN0A are
short, regular height adapters.
Each port provides single initiator capability over a bre link or with NPIV, multiple initiator capability is
provided. The ports are SFP+ and include an optical SR transceiver. The ports have little connector-type
(LC) and utilize shortwave laser optics. The adapter operates at link speeds of 4, 8 and 16 Gbps and will
automatically negotiate to the highest speed possible. LEDs on each port provide information on the
status and link speed of the port.
The adapter connects to a Fibre Channel switch at 4 Gb, 8 Gb or 16 Gb. It can directly attach to a device
without a switch at 16 Gb. Attachment without a switch is not supported at 4 Gb or 8 Gb.
N_Port ID Virtualization (NPIV) capability is supported through VIOS.
The adapter has the following features:
• This adapter has parts and construction compliant with the European Union Directive of Restriction of
Hazardous Substances (RoHS)
• The adapter is compliant with the PCIe base and Card Electromechanical (CEM) 2.0 specications with
the following characteristics:
– Provides an x8 lane link interface at 14.025 Gbps, 8.5 Gbps, or 4.25 Gbps (automatic negotiation
with system)
– Provides support for one Virtual Channel (VC0) and one Trafc Class (TC0)
– Provides conguration and I/O memory read and write, completion, and messaging capabilities
– Provides support for 64-bit addressing
– Provides error correction code (ECC) and error protection functions
– Provides link cyclic redundancy check (CRC) on all PCIe packets and message information
– Provides a large payload size of 2048 bytes for read and write functions
– Provides a large read request size of 4096 bytes
• The adapter is compatible with 4, 8, and 16 Gb Fibre Channel interface with the following
characteristics:
– Provides for automatic negotiation between 4 Gb, 8 Gb, or 16 Gb link attachments
– Provides support for the following Fibre Channel topologies: point-to-point (16Gb only) and fabric
– Provides support for Fibre Channel class 3
172
Power Systems: Managing PCIe adapters
