Slot requirement
For details about slot priorities, maximums, and placement rules, see PCIe adapter placement rules
and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER9/p9eab/
p9eab_mtm_pciplacement.htm) and select the system you are working on.
Voltage
3.3 V, 12 V
Form factor
Short, low-prole (FC EC5E and EC6Y)
Short, with full-height tailstock (FC EC5F and EC6Z)
Maximum number
For details about the maximum number of adapters that are supported, see PCIe adapter placement
rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER9/p9eab/
p9eab_mtm_pciplacement.htm) and select the system you are working on.
Attributes provided
6.4 TB of low latency flash memory
Non-Volatile Write Buffer
Hot Plug Capable
Operating system or partition requirements
If you are installing a new feature, ensure that you have the software that is required to support the new
feature. You must also determine whether any prerequisites must be met for this feature and devices that
are attached to the adapter. For information about operating system and partition requirements, see one
of the following topics:
• The latest version of enabling libraries and utilities can be downloaded from Fix Central
(http://
www.ibm.com/support/xcentral/).
• Power Systems Prerequisites (http://www14.software.ibm.com/support/customercare/iprt/home).
• IBM SSIC (System Storage Interoperation Center) (http://www-03.ibm.com/systems/support/storage/
ssic/interoperability.wss).
• The latest version of the NVMe management tool can be downloaded from the IBM Service and
Productivity Tools website (http://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/home.html).
• For support details, see the Linux Alert website (http://www14.software.ibm.com/webapp/set2/sas/f/
lopdiags/info/LinuxAlerts.html).
PCIe4 x16 1-Port EDR 100 GB IB ConnectX-5 CAPI Capable Adapter (FC EC62 and EC63; CCIN 2CF1)
Learn about the specications and operating system requirements for feature code (FC) EC62 and EC63
adapters.
Overview
FC EC62 and EC63 are both the same adapter with different feature codes. FC EC62 is a low-prole
adapter and FC EC63 is a full-height adapter.
The PCIe4 x16 1-Port enhanced data rate (EDR) 100 GB Inniband (IB) ConnectX-5 CAPI Capable
Adapter is a PCI Express (PCIe) generation 4 (Gen4) x16 adapter. The adapter enables higher HPC
performance with new Message Passing Interface (MPI) offloads, such as MPI Tag Matching and MPI
AlltoAll operations, advanced dynamic routing, and new capabilities to perform various data algorithms.
Note: The Virtual Protocol Interconnect (VPI) feature is not supported on this adapter. The adapter must
be used only as an InniBand adapter.
Managing PCIe adapters
117
