Voltage
12 V
Form factor
Short, regular-height
Cables
The 10 Gb ports are SFP+ ports and include an optical LR transceiver. The ports have LC Duplex type
connectors and utilize longwave laser optics and 1310 nm ber cabling. With 9 micron OS1, up to 10
kilometer length ber cables.
For the 1 Gb RJ45 ports, 4-pair CAT-5 Unshielded Twisted Pair (UTP) cable or higher is supported for
a distance of up to 100 meters.
Table 39. Cable type
Fiber cable type Connector type Operating range in meters
9 μm SMF LC 10 km
Operating system or partition requirements
If you are installing a new feature, ensure that you have the software that is required to support the new
feature and that you determine whether any prerequisites must be met for this feature and attaching
devices. For information about operating system and partition requirements, see one of the following
topics:
• The latest version of enabling libraries and utilities can be downloaded from Fix Central
(http://
www.ibm.com/support/xcentral/).
• Power Systems Prerequisites (http://www14.software.ibm.com/support/customercare/iprt/home).
• IBM SSIC (System Storage Interoperation Center) (http://www-03.ibm.com/systems/support/storage/
ssic/interoperability.wss).
• The latest version of the device driver or IBM Power RAID adapter utilities (iprutils) can be downloaded
from the IBM Service and Productivity Tools website (http://www14.software.ibm.com/webapp/
set2/sas/f/lopdiags/home.html).
• For support details, see the Linux Alert website (http://www14.software.ibm.com/webapp/set2/sas/f/
lopdiags/info/LinuxAlerts.html).
PCIe2 4-port (10 Gb + 1 GbE) SR / Copper SFP +RJ45 adapter (FC EN0S, FC EN0T, FC EN0U, and FC
EN0V; CCIN 2CC3)
Learn about the specications and operating system requirements for the feature code (FC) EN0S, FC
EN0T, FC EN0U, and FC EN0V adapters.
Overview
The PCIe2 4-port (10 Gb + 1 GbE) SR / Copper SFP +RJ45 adapter is a PCI Express (PCIe) generation 2
(Gen2) x8, short form-factor adapter.
• The FC EN0S and EN0U are short, full height adapters. FC EN0S is an SR adapter whereas FC EN0U is a
Copper SFP adapter.
• The FC EN0T and EN0V are short, low-prole adapters. FC EN0T is an SR adapter whereas FC EN0V is a
Copper SFP adapter.
The adapter provides two 10 Gb SR optical ports and two 1 Gb RJ45 ports. This adapter provides a PCIe
2.0 host bus interface. The adapter supports the Ethernet network interface controller (NIC) function. The
adapter is a high-performance adapter that consolidates trafc for networking. The link aggregation and
failover features of the adapter make it suitable for critical network applications that require redundancy
and high availability.
The four-port adapter provides two 10 Gb small form-factor pluggable (SFP+) optical SR transceiver ports
and two 1 Gb RJ45 Ethernet ports. The two 10 Gb SR ports have little connector (LC) duplex-type
194
Power Systems: Managing PCIe adapters

IBM 74Y4064 Specifications

General

Brand	IBM
Model	74Y4064
Category	Adapter
Language	English
