• Where applicable, show special installation or cabling instructions
• Show signal names for the output-pins of the adapter connectors
• Where applicable, show the settings for switches or jumpers
Adapters can be identied by their feature code (FC) or their custom-card identication number (CCIN).
Normally, the CCIN number is labeled on the adapter. The eld replaceable unit (FRU) part number (P/N)
of your adapter might not match the FRU P/N listed in this information. If the part numbers do not match,
verify that the CCIN is the same. If the CCIN is same, the adapter has the same function and can be used
in the same way.
Adapters must be placed in specic PCI Express (PCIe) slots to function correctly or optimally.
SAS RAID internal adapters and controllers for the 9009-41A, 9009-42A, or 9223-42H system
Find information about the PCIe3 SAS RAID internal adapters and controllers that are installed and
supported in the system.
Table 5 on page 5 provides information about the SAS RAID cards that are supported for the
9009-41A, 9009-42A, or 9223-42H system.
Table 5. SAS RAID Controllers supported for the 9009-41A, 9009-42A, or 9223-42H system
Feature Code Description Function
EJ1C Single - PCIe3 x8 SAS RAID
Internal Adapter 6 Gb (FC EJ1C;
CCIN 57D7); Adapter FRU
number: 01LK399
Storage backplane with integrated SAS controller
for SAS bays and DVD in the system unit. SAS
bays are 2.5-inches or Small Form Factor (SFF)
and use drives that are mounted on a carrier/tray
specic to the system unit (SFF-3).
The high-performance SAS controller provides
RAID-0, RAID-5, RAID-6 and RAID-10 support for
either HDD or SSD. JBOD support for HDD is also
supported. Controller has no write cache.
EJ1E Split Disk - PCIe3 x8 SAS RAID
Internal Adapter 6 Gb (FC EJ1E;
CCIN 57D7); Adapter FRU
number: 01LK399
The high-performance SAS controllers each
provides RAID-0, RAID-5, RAID-6 and RAID-10
support. JBOD support for HDD is also supported.
There is no write cache on either controller.
EJ1D 18 SFF - PCIe3 x8 cache SAS
RAID internal adapter 6 Gb (FC
EJ1D; CCIN 57D8); Adapter FRU
number: 01JC773
Storage backplane with dual integrated SAS
controllers with write cache. High-performance
controllers run SFF-3 SAS bays, 1.8-inch SSD
cage bays if supported, and DVD bay in the system
unit. Dual controllers (also called dual I/O
adapters or paired controllers) and their write
cache are placed in integrated slots and do not
use PCIe slots.
The high-performance SAS controllers provide
RAID-0, RAID-5, RAID-6, RAID-10, RAID-5T2,
RAID-6T2, and RAID-10T2 support. Patented
Active/Active congurations with at least two
arrays is supported.
Managing PCIe adapters 5
