Maximum number
For details about the maximum number of adapters that are supported, see PCIe adapter placement
rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER9/p9eab/
p9eab_mtm_pciplacement.htm) and select the system you are working on..
Attributes provided
32 Gb/s of throughput.
Enhanced diagnostics and manageability.
Unparalleled performance and more efcient port usage.
Single initiator capability over a ber link or with NPIV.
Multiple initiator capabilities.
Operating system or partition requirements
If you are installing a new feature, ensure that you have the software that is required to support the new
feature and that you determine whether any prerequisites must be met for this feature and attaching
devices. For information about operating system and partition requirements, see one of the following
topics:
• The latest version of enabling libraries and utilities can be downloaded from Fix Central (http://
www.ibm.com/support/xcentral/).
• Power Systems Prerequisites
(http://www14.software.ibm.com/support/customercare/iprt/home).
• IBM SSIC (System Storage Interoperation Center) (http://www-03.ibm.com/systems/support/storage/
ssic/interoperability.wss).
• The latest version of the device driver or IBM Power RAID adapter utilities (iprutils) can be downloaded
from the IBM Service and Productivity Tools website (http://www14.software.ibm.com/webapp/
set2/sas/f/lopdiags/home.html).
• For support details, see the Linux Alert website (http://www14.software.ibm.com/webapp/set2/sas/f/
lopdiags/info/LinuxAlerts.html).
PCIe3 x8 4-port Fibre Channel (16 Gb/s); (FC EL5W, EL5X, EN1C, and EN1D; CCIN 578E)
Learn about the specications and operating system requirements for feature code (FCs) EL5W, EL5X,
EN1C, and EN1D (EL5X) adapters.
Overview
The FC EN1C (EL5W) and EN1D (EL5X) are electronically identical. FC EN1C (EL5W) is a full-height
adapter and FC EN1D (EL5X) is a low-prole adapter.
The PCIe3 x8 4-port bre Channel (16 Gb/s) Adapter is a PCI Express (PCIe) generation 3 (Gen3) x8
adapter. The adapter can be used in either a x8 or x16 PCIe slot in the system. This adapter is a high-
performance is based on the Broadcom LPe31004-series PCIe host bus adapter (HBA). The adapter
provides four ports of 16 Gb Fibre Channel capability that uses SR optics. Each port can provide up to 16
Gb Fibre Channel functions simultaneously. Each port provides single initiator capability over a bre link
or with NPIV, multiple initiator capability is provided. The ports are SFP+ and include an optical SR
transceiver. The ports have LC type connectors and use shortwave laser optics. The adapter operates at
link speeds of 4, 8, and 16 Gbps and automatically negotiates to the highest speed possible. Each port
has two LED indicators that are located on the bracket next to each connector. These LEDs communicate
boot status and give a visual indication of the operating state. The LEDs have ve dened state; solid on,
solid off, slow blink, fast blink, and flashing. The slow blink rate is 1 Hz, the fast blink is 4 Hz, and the
flashing refers to an irregular on/off transition that reflects test progress. The operator should observe the
LED sequence for several seconds to ensure that the operating state is correctly identied.
216
Power Systems: Managing PCIe adapters

IBM 74Y4064 Specifications

General

Brand	IBM
Model	74Y4064
Category	Adapter
Language	English
