Table 20. Cable type and distance (10 Gb/s)
Rate Cable type and distance
10 Gb/s OM1 OM2 OM3
0.5 m to 33 m (1.64 ft to
108.26 ft)
0.5 m to 82 m (1.64 ft to
269.02 ft)
0.5 meters to 300
meters (1.64 ft to
984.25 ft)
Table 21. Optical transceivers and cables
Feature code Description
EB46 10 Gb optical transceiver (purchased separately)
EN01 10 Gb/s 1 m (3.3 ft) copper active twinax Ethernet
cable
EN02 10 Gb/s 3 m (9.8 ft) copper active twinax Ethernet
cable
EN03 10 Gb/s 5 m (16.4 ft) copper active twinax
Ethernet cable
Operating system or partition requirements
If you are installing a new feature, ensure that you have the software that is required to support the new
feature and that you determine whether any prerequisites must be met for this feature and attaching
devices. For information about operating system and partition requirements, see one of the following
topics:
• The latest version of enabling libraries and utilities can be downloaded from Fix Central (http://
www.ibm.com/support/xcentral/).
• Power Systems Prerequisites (http://www14.software.ibm.com/support/customercare/iprt/home).
• IBM SSIC (System Storage Interoperation Center) (http://www-03.ibm.com/systems/support/storage/
ssic/interoperability.wss).
• The latest version of the device driver or IBM Power RAID adapter utilities (iprutils) can be downloaded
from the IBM Service and Productivity Tools website (http://www14.software.ibm.com/webapp/
set2/sas/f/lopdiags/home.html).
• For support details, see the Linux Alert website (http://www14.software.ibm.com/webapp/set2/sas/f/
lopdiags/info/LinuxAlerts.html).
PCIe3 2-port 25/10 Gb NIC & RoCE SFP28 adapter (FC EC2T and FC EC2U; CCIN 58FB)
Learn about the specications and operating system requirements for feature code (FC) EC2T and FC
EC2U adapters.
Overview
FC EC2T and EC2U are both the same adapter with different feature codes. FC EC2T is a low-prole
adapter, and FC EC2U is a full-height adapter.
The PCIe3 2-PORT 25/10 Gb NIC & RoCE SFP28 Adapter (FC EC2T and EC2U) is a PCI Express (PCIe)
generation 3 (Gen3) x8 adapter. The adapter provides two 25 Gb SFP28 ports. The adapter supports both
the Ethernet network interface controller (NIC) function and RDMA over Converged Ethernet (RoCE).
Using RoCE, the adapter can support signicantly greater bandwidth with low latency. It also minimizes
CPU overhead by more efciently using memory access. This offloads the CPU from I/O networking tasks,
improving performance and scalability.
Managing PCIe adapters
81
