IBM 74Y4064 User Manual

Adapter FRU number
00WT111 (Designed to comply with RoHS requirement)
I/O bus architecture
PCIe2.0 x8
Slot requirement
For details about slot priorities, maximums, and placement rules, see PCIe adapter placement rules
and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER9/p9eab/
p9eab_mtm_pciplacement.htm) and select the system you are working on.
FC compatibility
2, 4, 8 Gigabit
Cables
Cables are the responsibility of the customer.
Use multimode ber optic cables with shortwave lasers that adhere to the following specications:
• OM3: Multimode 50/125 micron ber, 2000 MHz x km bandwidth
• OM2: Multimode 50/125 micron ber, 500 MHz x km bandwidth
• OM1: Multimode 62.5/125 micron ber, 200 MHz x km bandwidth
Because core sizes are different, OM1 cables can only be connected to other OM1 cables. For best
results, OM2 cables should not be connected to OM3 cables. However, if an OM2 cable is connected
to an OM3 cable, the characteristics of the OM2 cable apply to the entire length of the cables. The
following table shows the supported distances for the different ber optic cable types at different link
speeds.
Table 35. Supported distances for multimode
ber optic cables
Header Cable Type and Distance
Rate OM1 OM2 OM3
2.125 Gbps 0.5 meters to 150
meters (1.64 feet to
492.12 feet)
0.5 meters to 300
meters (1.64 feet to
984.25 feet)
0.5 meters to 500
meters (1.64 feet to
1640.41 feet)
4.25 Gbps 0.5 meters to 70
meters (1.64 feet to
229.65 feet)
0.5 meters to 150
meters (1.64 feet to
492.12 feet)
0.5 meters to 380
meters (1.64 feet to
1246.71 feet)
8.5 Gbps 0.5 meters to 21
meters (1.64 feet to
68.89 feet)
0.5 meters to 50
meters (1.64 feet to
164.04 feet)
0.5 meters to 150
meters (1.64 feet to
492.12 feet)
Voltage
12 V
Form factor
Short, low-prole (FC EL5Y and FC EN0F)
Short, with full-height tailstock (FC EL5Z and FC EN0G)
Maximum number
For details about the maximum number of adapters that are supported, see PCIe adapter placement
rules and slot priorities (http://www.ibm.com/support/knowledgecenter/POWER9/p9eab/
p9eab_mtm_pciplacement.htm) and select the system you are working on.
Attributes provided
NPIV capability is supported through VIOS
Requires a PCI Express Gen2 x8 slot for all ports to operate at full speed
Managing PCIe adapters
179
