003 (continued)
– If the phone line is bad, tell the customer to contact the
telephone company. The Mwave card does not need
replacing.
004
DOES THE SYSTEM FAIL TO WAKE UP WHEN THE WAKE UP ON
RING FEATURE IS ENABLED IN THE CONFIGURATION UTILITY?
Yes No
005
– The Wake Up on Ring feature is working normally. If the
symptom remains, go to “Index of Symptoms, Messages,
Error Codes, or Beeps” on page 2-9.
006
– Power-off the system unit.
– Power-on the system unit and press F1 while the memory count is
running.
– In the Setup Utility, select the Rapid Resume option. (If you cannot
access Rapid Resume, replace the system board.)
– If disabled, use the ← key to enable APM BIOS Mode (top line of
screen)
– Press the ← key to disable or enable both the Wake Up on Ring
and Ring Indicator fields.
CAN THE WAKE UP ON RING FEATURES BE ENABLED IN THE
CONFIGURATION UTILITY?
Yes No
007
Replace the system board.
008
– Check the Wake Up on Ring feature cable from the system board to
the Mwave card for continuity. Replace if necessary.
– Check for proper installation of the Wake Up on Ring cable to the
system board. See “System Board Layout—Type A-1” on page 5-2
and “System Board Layout—Type A-2” on page 5-5
(Step 008 continues)
Check Procedures 2-59
