1085—Indicator LED and Cable
Left drive support bracket (1010).
Right drive support bracket (1015).
Push in on the indicator LED and remove assembly from the rear.
Indicator LED
and cable
Figure 4-17. Indicator LED and Cable
Repair Information 4-17
