IBM Aptiva 2134 - Assembly 7: Monitor and Power Cord (Linecord)

Assembly 7: Monitor and Power Cord (Linecord)
1
2
Asm– Part
Index Number Units Description
7–1 Monitor (includes I/O cable)
–2 Stand (included with monitor)
EQ = Equatorial
NH = Northern hemisphere
SH = Southern hemisphere
LV = Low Voltage
HV = High Voltage
UV = Universal Voltage (auto-sense)
See the Appendix B, “Model/Monitor
Configurations and FRU Part
Numbers” on page B-1 for model
specifications.
For monitors sold separately from IBM
Aptiva system units, see the service
information provided with the monitor.
EMEA uses Express Repair for
Monitors.
14-Inch Monitor - Type 6542
(12.3-Inch diagonal viewing area)
(P1438-G40) SVGA Monitor
–1 96G3108 1 - .28, 100/240 V 50/60 Hz, NH/UV
–1 96G3109 1 - .28, 100/240 V 50/60 Hz, EQ/UV
7-16
