2050—Memory (SIMM)
Attention: Memory modules are sensitive to static discharge. See
“Handling ESD-Sensitive Parts” on page 4-38.
Adapter cards (2035) if applicable.
Riser card (if SIMMs located behind riser card).
Push out on the side clamps to release the module.
Pull the module up and out to remove.
Note: Run the Setup Utility after adding or removing memory.
clip
memory module (SIMM)
socket
72-pin memory
module (SIMM)
memory module
socket
Figure 4-30. Memory SIMM
Repair Information 4-29
