2045—Riser Card
Adapter cards (2035) if applicable.
Riser card power connector.
Remove the riser card mounting screw (1).
Remove the riser card (2).
(Front)
(Top)
(Back)
(Bottom)
Riser Card
Connector
Riser
Card
2
3
1
System Board
Riser Card Clip
Figure 4-29. Riser Card
4-28
