B
A
91357
(Connector side)
(Pin side)
91357
A
B
Figure 2-6. Riser Cards - Machine Types 2134 and 2176
ARE THE VOLTAGES CORRECT?
Yes No
014
Replace the riser card. If the symptom remains, replace the system
board.
015
Check all jumper and switch settings.
If the symptom remains, replace the Mwave adapter card.
– or –
Replace the system board.
Check Procedures 2-61
To Next Page
