Asm– Part
Index Number Units Description
2–1 System Board
Note: See the Appendix B,
“Model/Monitor Configurations and
FRU Part Numbers” on page B-1 for
model specifications.
All system board FRUs are shipped
without processor, cache memory
modules, video DRAM modules, or
SIMMs. When replacing a system
board, remove all FRUs from the
original system board and install them
on the new system board.
–1 12H2015 1 System Board - Type A-1
–1 12H2001 1 System Board - Type A-2
–NS 07H0973 1 Voltage Regulator (Type A-2 Only)
–2 06H6063 1 P54C-100 MHz Processor
–2 75H8963 1 P54C-120 MHz Processor
–2 06H8228 1 P54C-133 MHz Processor
–2 06H9892 1 P54C-150 MHz Processor
–2 07H0971 1 P54C-166 MHz Processor
–2 75H9575 1 P54C-200 MHz Processor
–NS 13H8071 1 Processor Fan
–3 06H7225 1 Riser Card (ISA/PCI)
–4 75H8905 1 Diskette Drive Cable
–5 60G2254 1 CD-ROM/Hard Disk Drive Cable
–6 13H8078 1 Dual LED Indicator Cable
–NS 76H1777 1 Hard Disk Drive Ribbon Cable
–7 06H3862 1 Power Supply (3.3V dc)
(145-W LV/HV Switch-selectable)
–8 60G2258 1 Power Switch and Cable
–9 92G7319 1 SIMM EDO, 4 MB, 72-Pin Non-Parity
–9 92G7321 1 SIMM EDO, 8 MB, 72-Pin Non-Parity
–9 92G7323 1 SIMM EDO, 16 MB, 72-Pin Non-Parity
–NS 07H1150 1 L2 Cache 256 KB (1 module)
–NS 93F0063 1 Lithium Battery (CR2032)
Parts Catalog 7-5
