Asm– Part
Index Number Units Description
4–1 System Boards
Note: See the Appendix B,
“Model/Monitor Configurations and
FRU Part Numbers” on page B-1 for
model specifications.
All system board FRUs are shipped
without processor, cache memory
modules, video DRAM modules, or
SIMMs. When replacing a system
board, remove all FRUs from the
original system board and install them
on the new system board.
–1 12H2015 1 System Board - Type A-1
–1 12H2001 1 System Board - Type A-2
–NS 07H0973 1 Voltage Regulator (Type A-2 Only)
–2 06H6063 1 P54C-100 MHz Processor
–2 75H8963 1 P54C-120 MHz Processor
–2 06H8228 1 P54C-133 MHz Processor
–2 06H9892 1 P54C-150 MHz Processor
–2 07H0971 1 P54C-166 MHz Processor
–2 75H9575 1 P54C-200 MHz Processor
–NS 06H1796 1 Processor Fan
–3 11H8453 1 Riser Card, ISA/PCI
–3 12H2025 1 Riser Card, ISA/PCI (TV models Only)
–4 60G2077 1 Bracket, Riser Card Support
–5 76H1585 1 3.5-in. Bay Blank Panel (Zip Drive)
–5 42H0344 1 3.5-in. Bay Blank Panel (Diskette
Drive)
–6 42H0345 1 5.25-in. Bay Blank Panel
–7 42H0347 1 Blank Audio Panel
–8 34G1861 1 Pedestal
–9 60G2254 1 CD-ROM/Hard Disk Drive Cable
–10 75H8905 1 Diskette Drive Cable
–NS 76H1777 1 Hard Disk Drive Ribbon Cable
–11 1 Mwave Card, see page 7-13.
Sound Card, see page 7-13.
Modem Card, see page 7-13.
Parts Catalog 7-9
