1035—Adapter Cards
Remove any cables (note location of cables).
Reset jumpers on adapter cards.
Adapter Card Connector
Adapter Card
Figure 4-9. Adapter Cards
Note: When reinstalling a modem adapter card, ensure the modem Wake
Up on Ring cable is connected from the 2-pin keyed connector on the
modem to the system board. See “System Board Layout—Type I-1” on
page 5-2 and “System Board Layout—Type I-2” on page 5-5 for connector
locations.
4-10
