2085—Indicator LED and Cable

 Push in on the indicator LED and remove from the rear.

 Disconnect the LED and cable from the system board.

See “Parts/Test Point Locations” on page 5-1 for LED and cable locations.

Indicator LEDs

Repair Information 4-39
