The MWave card, as shown below, has no jumpers to set.
Line In
Phone
Microphone Input
Audio Output
Joystick/MIDI
Adapter Plug
Figure 5-19. MWave Card (Combination Modem/Sound)
Parts/Test Point Locations 5-17
