IBM Aptiva 2144 User Manual

Table 5-4 (Page 2 of 2). ISA Riser Connector
Description Pin Pin Description
Ground B35 A35 Ground
VCC B36 A36 Ground
VCC B37 A37 VCC
M 16 B38 A38 SBHE
IO 16 B39 A39 LA(23)
IRQ10 B40 A40 LA(22)
IRQ11 B41 A41 LA(21)
IRQ12 B42 A42 LA(20)
IRQ15 B43 A43 LA(19)
IRQ14 B44 A44 LA(18)
DACK 0 B45 A45 LA(17)
DRQ0 B46 A46 MEMR
DACK 5 B47 A47 MEMW
DRQ5 B48 A48 SD(8)
DACK 6 B49 A49 SD(9)
DRQ6 B50 A50 SD(10)
DACK 7 B51 A51 SD(11)
DRQ7 B52 A52 SD(12)
VCC B53 A53 SD(13)
MASTER B54 A54 SD(14)
Ground B55 A55 SD(15)
Ground B56 A56 Ground
Ground B57 A57 Ground
VCC B58 A58 Ground
VCC B59 A59 VCC
VCC B60 A60 VCC
Parts/Test Point Locations 5-27
